Type M JC Skid Steer Loader

	Model	JC25M	JC30M	JC35M	JC45M	JC60M	JC65M
	Operating load (kg)	300	450	500	700	850	950
	Max Speed（km/h）	9	10	10	12	12	12
	Rated flux (L/min)	37	50	60	62.5	75	75
	Tire（track） model	23×8.5-15	27×8.5-15	8.5-15	10-16.5	12-16.5	12-16.5
	Rated power (Kw)	18.4	22	29.5	37	45	55
	Fuel tank capacity (L)	25	45	60	70	70	80
	Self weight bucket (kg)	1500	2000	2300	2700	2800	3000
	Bucket capacity (m3)	0.2	0.3	0.3	0.4	0.4	0.5
A	Overall operating height (mm)	3126	3430	3300	3980	4130	4130
B	Height to bucket hinge pin (mm)	2399	2633	2725	3080	3130	3130
C	Height to top of cab (mm)	1813	1878	2000	2120	2170	2170
D	Height to bottom of level bucket(mm)	2399	2663	2558	2200	2250	2250
E	Overall length ithout bucket（mm）	1918	2262	2300	2710	2810	2810
F	Overall length with bucket(mm)	2560	2929	2950	3490	3595	3595
G	Dumping angle at maximum height(° )	36	43	40	40°	40	40
H	Dumping height(mm)	1882	1971	2050	2380	2400	2400
I	Dumping reach(mm)	458	477	790	750	750	750
J	Rollback o bucket on ground(° )	24	26	30	30°	30	30
K	Rollback of bucket at full height(° )	97	95	104	105°	105	105
L	Wheelbase(mm)	722	818	897	991	991	1080
M	Ground clearance(mm)	148	167	140	185	210	210
N	Angle of departure(° )	28	25	20	20°	20	20
O	Front turning radins without bucket(mm)	971	1135	1098	1168	1198	1204
P	Front tuning radius(mm)	1557	1819	1760	1550	1550	1550
Q	Rear tuning radius(mm)	1146	1339	1296	1350	1450	1450
R	Rear axle to bumper (mm)	738	967	964	1108	1208	1082
S	Tread width,enterline to centerline (mm)	747	967	1080	1450	1500	1500
T	Width (mm)	900	1182	1350	1580	1682	1682
U	Bucket width (mm)	914	1267	1400	1680	1700	1700
