RHG04 Stone Grapple for 5-8T Excavator

RHG04 Wood/Stone Grapple is used on 5-8 tons of excavator. The max jaw opening is 1371mm. 2+3 fingers or 3+4 fingers, 360º rotation or not is depending on your demands.
  • RHG04

  • RAY ATTACHMENTS

Availability:

Rotating Stone Grapple Products Description

Applications: Including the handling of stones, pipes, disposable waste, landscaping works, and many others.

According to to be stacked capture material density is divided into light, medium, heavy, and super heavy.

Stone Type: Durable teeth to Increase the friction and keep the stone never falling down.


RAY hydraulic stone grapple.jpg


Why choose our grapple?

Good quality:

       1. Export motor hydraulic: Driven by M+S motor with brake valve

       2. Using high strength rotating support device. The operator can control the rotating speed. 360 degree clockwise and anticlockwise rotating.

       3. Cylinder with USA safety valve (USA SUN brand). It is equipped with non-return valve, more safety for grabbing.

       4. 3+2,4+3,5+4 fingers for your option,grab thing more stable

       5. Throttle, pressure reducing valve, relief valve (all the valves are USA SUN brand) are in electrical and hydraulic control system, making it safer and much more stable and durable in use.

       6. Flexible design: The grabbing shape of RAY grapple can be customized as customers' request in order to meet operation requirement. It also can be made confirmed.

       7. Light weight with wide opening jaws show outstanding performance of grabbing as well as maximizing operating efficiency.


RAY stone grapple.jpg


How to choose the stone grapple?


  1. Make sure of the weight of your carrier.

  2. Make sure of the oil flow of your excavator.

  3. Make sure of the wood or stone which you want to carry.



Rotating Stone Grapple Data


Specification: (Wood/Stone Grapple)
Model Unit RHG03 RHG04 RHG06 RHG08 RHG10 RHG14
Weight Kg 400 450 860 1500 1600 1700
Jaw Opening mm 1280 1371 1539 2492 2492 2492
Working Pressure Kg/cm² 110-140 120-160 150-170 160-180 160-180 160-180
Setting Pressure Kg/cm² 170 180 190 200 210 250
Oil Flow l/m 30-55 50-100 90-110 100-140 130-170 200-250
Cylinder pcs 2 2 2 2 2 2
Carrier ton 3-5 5-8 9-16 17-23 24-30 30-40
Standard finger 2+3
Optional finger 3+4
* This specifications are subject to change without prior notice for the improvement of quality.
