Model | Unit | RCG-02A | RCG-02B | RCG-04 | RCG-06A | RCG-06B |
Carrier | Ton | 2.5-4.5 | 4-6 | 6-8 | 10-15 | 15-18 |
Cylinder | Bar | 250 | 300 | 350 | 350 | 350 |
Cylinder | Liters/min | 8-15 | 10-20 | 15-30 | 30-65 | 40-80 |
360° rotation | Bar | 100 | 100 | 100 | 140 | 140 |
360° rotation | Liters/min | 6-9 | 8-12 | 8-12 | 12-20 | 12-20 |
360° rotation | Rpm | 10-15 | 10-15 | 10-15 | 10-15 | 10-15 |
Force | N | 12000 | 19000 | 25000 | 40000 | 50000 |
A | mm | 1090 | 1180 | 1290 | 1710 | 1830 |
B | mm | 770 | 850 | 960 | 1245 | 1360 |
C | mm | 770 | 825 | 910 | 1240 | 1335 |
D | mm | 830 | 860 | 945 | 1360 | 1435 |
L | mm | 400 | 460 | 550 | 800 | 900 |
Volume | L | 75 | 94 | 116 | 350 | 440 |
Weight | Kg | 210 | 260 | 370 | 745 | 950 |
1) Parker motor.
2) Interchangeability of machines is easy due to bolt-on adaptation plate.
3) Hydraulic rotation 360° in 2 directions to ease precise and fast positioning of the tool, with pressure control valve.
4) 1 or 2 cylinders give strong power on cutting edges for demolition.
5) Sturdy housing made of steel – high elastic with bolts.
6) Large capacity.
7) Cutting edges and Shell of Hardox for long life. Opening up to 90°.
