| Model | RSS450W | RSS600W | RSS650W | RSS750W | RSS1000W |
| Operating load (kg) | 700 | 850 | 950 | 1050 | 1200 |
| Max Speed（km/h） | 12 | 12 | 12 | 12 | 12/18 |
| Rated flux (L/min) | 62.5 | 75 | 75 | 75 | 75 |
| Tire（track） model | 10-16.5 | 12-16.5 | 12-16.5 | 12-16.5 | 12-16.5 |
| Rated power (Kw) | 37 | 45 | 55 | 55 | 74 |
| Fuel tank capacity (L) | 70 | 70 | 80 | 75 | 90 |
| Self weight bucket (kg) | 2700 | 2800 | 3000 | 3500 | 3550 |
| Bucket capacity (m3) | 0.4 | 0.4 | 0.5 | 0.5 | 0.55 |
| Overall operating height (mm) | 3980 | 4130 | 4130 | 4070 | 4070 |
| Height to bucket hinge pin (mm) | 3080 | 3130 | 3130 | 3150 | 3150 |
| Height to top of cab (mm) | 2120 | 2170 | 2170 | 2160 | 2160 |
| Height to bottom of level bucket(mm) | 2200 | 2250 | 2250 | 2983 | 2983 |
| Overall length ithout bucket（mm） | 2710 | 2810 | 2810 | 2880 | 2880 |
| Overall length with bucket(mm) | 3490 | 3595 | 3595 | 3580 | 3580 |
| Dumping angle at maximum height(° ) | 40° | 40 | 40 | 40 | 40 |
| Dumping height(mm) | 2380 | 2400 | 2400 | 2450 | 2450 |
| Dumping reach(mm) | 750 | 750 | 750 | 700 | 700 |
| Rollback o bucket on ground(° ) | 30° | 30 | 30 | 30 | 30 |
| Rollback of bucket at full height(° ) | 105° | 105 | 105 | 104 | 104 |
| Wheelbase(mm) | 991 | 991 | 1080 | 1115 | 1185 |
| Ground clearance(mm) | 185 | 210 | 210 | 205 | 205 |
| Angle of departure(° ) | 20° | 20 | 20 | 20 | 20 |
| Front turning radins without bucket(mm) | 1168 | 1198 | 1204 | 1250 | 1278 |
| Front tuning radius(mm) | 1550 | 1550 | 1550 | 2112 | 2144 |
| Rear tuning radius(mm) | 1350 | 1450 | 1450 | 1774 | 1857 |
| Rear axle to bumper (mm) | 1108 | 1208 | 1082 | 1082 | 1082 |
| Tread width,enterline to centerline (mm) | 1450 | 1500 | 1500 | 1500 | 1500 |
| Width (mm) | 1580 | 1682 | 1682 | 1880 | 1880 |
| Bucket width (mm) | 1680 | 1700 | 1700 | 1880 | 1880 |
